ABB INICT01 Protocol conversion module

ABB INICT01 Protocol conversion module

SPECIFIC PARAMETERS​

Brand ABB​

Product Series Industrial Network Interface Module Series​

Product Type Industrial Protocol Conversion Module​

Communication Protocols Profinet EtherNet/IP Modbus TCP​

Interface Type 2 Gigabit Ethernet Ports 1 RS-485 Serial Port​

Working Voltage 24VDC Wide Range Adaptation 19.2-28.8VDC​

Working Current Typical 0.3A Maximum 0.5A​

Working Temperature -25℃ to 70℃​

Storage Temperature -40℃ to 85℃​

Relative Humidity 5% to 95% Non-condensing​

Protection Level IP20 (In-cabinet Installation)​

Data Transmission Rate 1Gbps for Ethernet Ports Maximum 115.2Kbps for RS-485 Serial Port​

Size 100mm×45mm×160mm (Standard 3U Module Size)​

Weight 0.5kg​

Power Consumption Typical 8W Maximum 12W​

Certification Qualification CE UL CSA IEC 61158 IEC 61010-1​

Compatible System ABB System 800xA S800 Series Controllers Industrial Automation Control Systems​

Diagnostic Function Support Network Link Interruption Protocol Abnormality Data Loss Fault Detection​

Redundancy Support Support Ethernet Link Redundancy Realize Undisturbed Switching​

PRODUCT PERFORMANCE​

Supports bidirectional conversion of multiple mainstream industrial protocols, enabling seamless interconnection of Profinet, EtherNet/IP and Modbus TCP devices, breaking network communication barriers​

Gigabit Ethernet interface ensures high-speed data transmission with a rate of 1Gbps, meeting the needs of large-scale real-time data interaction in industrial scenarios​

RS-485 serial port with maximum 115.2Kbps transmission rate, adapting to the access of traditional industrial bus devices and taking into account the compatibility of old and new systems​

Wide input voltage design adapts to 19.2-28.8VDC, which can resist power grid fluctuations in industrial sites and ensure stable operation of the module​

Industrial-grade wide-temperature adaptation capability, can work continuously in the temperature range of -25℃ to 70℃, adapting to extreme industrial environments such as high temperature and low temperature​

Built-in network fault self-diagnosis function, real-time monitoring link status, protocol interaction and data transmission abnormalities to achieve rapid fault location and alarm​

Supports Ethernet link redundancy configuration, millisecond-level undisturbed switching when link fails, ensuring uninterrupted data transmission​

Modular 3U standard size design, easy to install, can be deployed collaboratively with industrial controllers and I/O modules, saving cabinet space​

Anti-electromagnetic interference design complies with industrial EMC standards, can resist on-site electromagnetic radiation and conducted interference, ensuring the integrity of communication signals​

Compatible with ABB System 800xA platform, supporting remote configuration and status monitoring, reducing system operation and maintenance difficulty​

Supports hot-swapping operation, can complete module maintenance without interrupting system operation, reducing equipment downtime​
