ABB IISAC01 3BHB006449R0002 Analog signal conversion module

ABB IISAC01 3BHB006449R0002 Analog signal conversion module

SPECIFIC PARAMETERS​

Brand ABB​

Product Series S800 Safety Series Safety Signal Conversion Module​

Product Type Safety-related Analog Signal Conversion Module​

Order Number 3BHB006449R0002​

Input Signal Type 4-20mA Current Signal​

Output Signal Type 4-20mA Current Signal​

Signal Conversion Accuracy 0.1% of Full Scale​

Working Voltage 24VDC Wide Range Adaptation 19.2-28.8VDC​

Working Current Typical 0.3A Maximum 0.5A​

Working Temperature -25℃ to 70℃​

Storage Temperature -40℃ to 85℃​

Relative Humidity 5% to 95% Non-condensing​

Protection Level IP20 (In-cabinet Installation)​

Isolation Feature Electrical Isolation Between Input and Output Isolation Voltage 250VAC​

Number of Channels 4 Independent Analog Signal Channels​

Response Time ≤10ms​

Size 100mm×45mm×180mm (Standard 3U Module Size)​

Weight 0.4kg​

Power Consumption Typical 3W Maximum 5W​

Certification Qualification CE UL CSA ATEX IECEx IEC 61508​

Compatible System ABB System 800xA S800 Safety Controllers Industrial Safety Instrumented Systems​

Diagnostic Function Support Signal Overrange Open-circuit Short-circuit Fault Detection​

PRODUCT PERFORMANCE​

4 independent channel design, capable of processing multiple 4-20mA analog signals simultaneously to achieve isolated signal conversion and precise transmission​

Signal conversion accuracy up to 0.1% of full scale, ensuring data integrity and accuracy during analog signal transmission​

250VAC electrical isolation between input and output, effectively blocking electromagnetic interference and fault conduction in industrial sites, improving system safety​

Complies with IEC 61508 SIL 2 safety standards, can be directly applied to safety control loops to ensure system functional safety level​

Built-in channel-level fault self-diagnostic function, real-time monitoring signal overrange, open circuit, short circuit and other abnormalities to achieve rapid fault location​

Industrial-grade wide-temperature adaptation capability, can operate continuously and stably in the temperature range of -25℃ to 70℃, adapting to extreme industrial environments​

Modular plug-in structure, supports hot-swapping operation, can complete module maintenance without interrupting system operation, reducing downtime​

Compatible with ABB System 800xA automation platform, can seamlessly cooperate with S800 Safety controllers to shorten system integration cycle​

Response time ≤10ms, meeting the real-time signal processing needs of industrial scenarios and ensuring timely triggering of safety interlock commands​

High-strength engineering plastic shell with anti-vibration design, can resist vibration and impact interference in industrial sites, ensuring stable module structure​
