ABB HVC-02B 3HNA024966-001/03 DCS High Voltage Control Module

ABB HVC-02B 3HNA024966-001/03 DCS High Voltage Control Module

Specific Parameters

Brand ABB (Switzerland)

Product Series HVC Series Industrial High-Voltage Control and Communication Module Series

Product Type Industrial-Grade DCS High-Voltage Control Module, PLC/DCS System Spare Part Module, Robot High-Voltage Control Board

Model ABB HVC-02B 3HNA024966-001/03

Country of Origin Switzerland

Compatible Devices ABB 800xA DCS System, PLC System, Industrial High-Voltage Equipment, Robot High-Voltage Components, Industrial Automation Control Equipment

Operating Power Supply 110V-380V AC

Rated Power Consumption 130W

Rated Current 30A

Output Frequency 50-60Hz

Control Precision ±0.5%

Communication Protocols Modbus TCP, EtherCAT, Profinet

Communication Interfaces 1 Ethernet Interface, 1 Gigabit Ethernet Interface, 1 RS-232C Interface, 1 Isolated Serial Interface

Protection Type Overload Protection, Overheating Protection, Short Circuit Protection, High-Voltage Isolation Protection, Electromagnetic Interference Protection

Operating Temperature Range -40℃ to 85℃

Storage Temperature Range -40℃ to 85℃

Relative Humidity 5% to 95%, Non-Condensing

Protection Level IP67

Physical Dimensions 116mm×56mm×35mm (Length×Width×Height)

Physical Weight Approximately 0.5kg

Mounting Method Standard DIN Rail Mounting, Built-in Slot Mounting for Industrial Control Equipment

Special Functions LED Status Indication, Fault Diagnosis, CPU Redundancy Design, Non-Volatile Storage, Multi-Module Collaborative Work

Product Material Aluminum Alloy

Customizable No

Certification Standards IEC 60255, CE, EMC

Warranty Period 12 Months

Product Performance

Compatible with ABB 800xA DCS and robot systems, powered by wide voltage, with a rated power consumption of 130W, it can operate 24 hours a day, and the spare part replacement is convenient to ensure the continuity of system control.

The control precision reaches ±0.5%, the rated current is 30A, the output frequency is stable, it can accurately realize high-voltage equipment control and robot drive, with fast response, meeting the needs of high-precision control.

Integrated with multiple safety protection and high-voltage isolation functions, it has strong anti-electromagnetic interference ability, complies with international certification standards, can effectively protect the safety of equipment and operators, and runs reliably.

With a protection level of IP67, the aluminum alloy material is strong and durable, with strong adaptability to wide temperature environments, and can operate stably in harsh scenarios such as outdoors and chemical plants, with a long service life.

Supports a variety of mainstream communication protocols and interfaces, seamlessly connects to various industrial systems, realizes real-time data transmission, integrates complete fault diagnosis functions, and has high operation and maintenance efficiency.
