ABB DSQC 697 DeviceNet Communication Interface Board
The ABB DSQC 697 DeviceNet Board is a high-quality industrial control solution designed for advanced manufacturing environments. It facilitates seamless communication between control systems and field devices, enhancing efficiency and reliability in automation processes.
Brand:ABB
Model:DSQC 697
Type:DeviceNet Board
Communication Protocol:DeviceNet
Data Rate:125 kbit/s or 250 kbit/s
Power Supply:24 V DC
Operating Temperature Range:-25°C to +60°C
Environmental Protection Rating:IP67
Weight:0.2 kg
Dimensions:120mm x 80mm x 40mm
The ABB DSQC 697 DeviceNet Board is a reliable solution for integrating DeviceNet communication into industrial control systems. With a robust design capable of withstanding harsh industrial environments, this module supports up to 64 nodes, enabling efficient data exchange across large-scale networks.
Equipped with a wide power supply voltage range of 18-32V DC, this board ensures compatibility with a variety of industrial power supplies. Its operating temperature range of -25°C to +60°C allows it to function in extreme conditions, making it ideal for use in diverse industrial settings.
With a compact form factor of 105 x 80 x 50 mm and a lightweight design weighing just 0.5 kg, the DSQC 697 can easily fit into tight spaces without compromising performance or functionality. Its IP20 rating provides basic protection against dust and accidental contact.
Designed with flexibility in mind, this DeviceNet board supports multiple network topologies including linear, tree, and ring configurations, allowing for customized network designs to meet specific application needs. Its modular architecture enables easy installation and maintenance.
By leveraging the ABB DSQC 697 DeviceNet Board, engineers and technicians can achieve seamless connectivity and efficient data exchange in industrial automation systems, enhancing overall system performance and reliability.
