ABB DO810 3BSE008510R1 Fiber optic communication module
Specific Parameters
- Number of Output Channels: 16 channels, divided into 2 isolated 8 – channel groups.
- Output Voltage Range: 10 to 30V DC, with a rated value of 24V DC.
- Output Current: The maximum output current per channel is 0.5A.
- Signal Type: Current – sourcing type, with current limiting function.
- Isolation Voltage: Electrical isolation is achieved between channel groups and between channel groups and the ground.
- Protection Functions: Equipped with short – circuit protection (against ground and 30V voltage), over – voltage protection, and over – temperature protection.
- Operating Temperature: 0°C to +55°C when installed horizontally; +5°C to +55°C when installed vertically.
- Storage Temperature: -40°C to +70°C.
- Installation Method: DIN rail installation.
- Dimensions (Width x Depth x Height): 45mm x 102mm (111mm with connector) x 119mm.
- Weight: 0.18kg.
- Response Time: Less than 1ms.
- Communication Interface: Supports industrial communication protocols such as Profibus – DP V1.
- Connection Method: Connected through module terminal units such as TU810, TU812, TU814, and TU830.
- Certification: Complies with UL and CE standards.
Product Performance
- High Reliability: With industrial – grade design and high – quality components, it can operate stably in harsh industrial environments, reducing the probability of system failures.
- High – Density Output: 16 output channels are integrated in a compact space, reducing the number of system hardware and space occupation, and lowering costs.
- Group Isolation and Voltage Monitoring: The output channels are grouped and isolated, and with process voltage monitoring, a channel error signal will be issued if the process voltage disappears, improving system diagnosis and reliability.
- Comprehensive Protection Functions: Each output channel is integrated with multiple protections to prevent module damage caused by external faults or overloads, enhancing system security.
- Output Status Indication: Each output channel is equipped with an LED indicator to intuitively display the output switch status, facilitating on – site monitoring and troubleshooting. The module itself is also equipped with operation, fault, warning, and OSP (Output Set as Predetermined) indicators to provide comprehensive status information.
- OSP Function: Supports the OSP function, and when an error occurs, the output can be set to a preset state to ensure the safe operation of the system.
- Seamless Integration: As a member of the S800 I/O series, it can be easily integrated with various ABB control systems, simplifying system design and configuration.
