ABB CSA464AE HIEE400106R0001 DC speed regulator module

ABB CSA464AE HIEE400106R0001 DC speed regulator module

Specific Parameters

• Input signal types: Thermocouples (K, J, T, E types), RTDs (Pt100, Cu50), mV signals (0-100mV)
• Output signal types: 4-20mA, 0-10V, 0-5V (configurable)
• Conversion accuracy: ±0.1% full scale
• Isolation voltage: 2500V AC between input and output; 2500V AC between power supply and input/output
• Power supply voltage: 24V DC±10%
• Power consumption: Maximum 5W
• Operating temperature range: -20°C to +60°C
• Storage temperature range: -40°C to +85°C
• Protection class: IP20
• Dimensions: 110mm×80mm×40mm
• Weight: 0.3kg
• Response time: ≤100ms
• Filter function: Configurable low-pass filter (cutoff frequency 1Hz-100Hz)

Product Performance

• High-precision signal conversion: Conversion accuracy reaches ±0.1% full scale, which can accurately capture small signal changes, ensuring the measurement data of thermocouples, RTDs and other devices are true and reliable.
• Strong isolation and anti-interference: 2500V AC triple isolation design combined with configurable filtering function effectively suppresses electromagnetic interference and ground loops in industrial sites, improving signal transmission stability by more than 90%.
• Wide signal compatibility: Supports multiple thermocouples, RTDs and mV-level input signals, and output signals can be configured via DIP switches without additional programming, adapting to various sensors and control systems.
• Stable environmental adaptation: Continuous operation in the operating temperature range of -20°C to +60°C, with no performance attenuation in 5%-95% humidity (non-condensing) environment, adapting to complex industrial scenarios such as high/low temperature and humidity.
• Convenient installation and maintenance: DIN rail mounting design, module indicators display power, input and output status in real time, and alarm automatically in case of failure, reducing troubleshooting time.
