ABB CSA463AE HIEE400103R0001 Signal isolation converter module
ABB CSA463AE HIEE400103R0001 is an industrial-grade intelligent signal isolation converter, designed for signal conditioning in industrial automation systems. The module can convert mV-level or resistance signals output by thermocouples, RTDs, pressure sensors and other devices into standard industrial signals (4-20mA, 0-10V), and realize electrical isolation between input, output and power supply, effectively suppressing electromagnetic interference, suitable for industrial scenarios requiring high-precision signal transmission.
wechatPhone 15359273787
Phone: 15359273787
Email: sales@zzhuie.com
connect：Mya
ABB CSA463AE HIEE400103R0001 Signal isolation converter module
Specific Parameters
- Input signal types: Thermocouples (K, J, T, E, S types), RTDs (Pt100, Cu50), mV signals (0-50mV)
- Output signal types: 4-20mA, 0-10V (configurable via DIP switches)
- Conversion accuracy: ±0.1% full scale
- Isolation voltage: 2500V AC between input and output; 2500V AC between power supply and input/output
- Power supply voltage: 24V DC±10%
- Power consumption: Maximum 4W
- Operating temperature range: -25°C to +70°C
- Storage temperature range: -40°C to +85°C
- Protection class: IP20
- Dimensions: 100mm×80mm×40mm
- Weight: 0.25kg
- Response time: ≤50ms
- Cold junction compensation error: ±0.5°C (for thermocouple input)
Product Performance
- High-precision signal conversion: Conversion accuracy reaches ±0.1% full scale, combined with cold junction compensation error of ±0.5°C, ensuring that the temperature deviation of thermocouple measurement is ≤1°C, meeting the high-precision requirements for temperature signals in chemical, metallurgical and other industries.
- Strong isolation and anti-interference: 2500V AC triple isolation design can cut off ground loops, suppress electromagnetic interference and surge impact in industrial sites, and improve signal transmission stability by more than 95%.
- Wide temperature stable operation: Within the operating temperature range of -25°C to +70°C, the module conversion accuracy does not attenuate, and can adapt to high and low temperature industrial environments, such as high-temperature areas of steel plants and cold storage monitoring systems.
- Flexible signal adaptation: Supports multiple thermocouples, RTDs and mV signal inputs, output types can be configured via DIP switches without software programming, and parameters can be set within 10 minutes.
- Convenient installation and maintenance: DIN rail mounting design, power supply, input and output status are displayed in real time through three-color indicators, and alarms are automatically given in case of faults, reducing troubleshooting time to within 5 minutes.
