ABB CP651-WEB Touch screen control panel
¥25,000.00 Original price was: ¥25,000.00.¥20,000.00Current price is: ¥20,000.00.
The ABB CP651 - WEB is an advanced touch - screen control panel specifically designed for industrial automation. It has powerful Web functions and is a key device for building the Human - Machine Interface (HMI) of industrial automation systems. It is equipped with a 10.4 - inch TFT liquid - crystal display screen with a resolution of 800×600 pixels and supports 64K color display, which can clearly present various industrial data and images. This device supports multi - touch operation, bringing users a convenient and intuitive operation experience. Its built - in Web server allows operators to remotely access and control through a browser, greatly enhancing the remote monitoring and maintenance capabilities of the device. In addition, the CP651 - WEB is fully compatible with ABB's PB610 software platform, facilitating users to build various industrial automation applications based on this platform.
wechatPhone 15359273787
Phone: 15359273787
Email: sales@zzhuie.com
connect：Mya
ABB CP651-WEB Touch screen control panel
Specific Parameters
- Display Screen: 10.4 – inch TFT liquid – crystal touch screen.
- Resolution: 800×600 pixels.
- Display Colors: 64K.
- Communication Interfaces:
- 2 Ethernet 10/100Mbit interfaces.
- 1 RS232/RS485/RS422 serial port.
- 2 USB 2.0 Host interfaces.
- 1 SD – card slot.
- 2 expansion slots.
- Power Supply: 24V DC (within the range of 18 – 30V DC).
- Storage:
- 256MB of user – data storage space (Flash Disk) built – in.
- 256MB of user – program storage space (DDR RAM).
- Protection Level: The front reaches IP66 according to the IEC 60529 standard, and the housing reaches IP20 according to the IEC 60529 standard.
- Operating Temperature Range: 0°C to +50°C.
- Storage Temperature Range: -20°C to +70°C.
- Dimensions (Length × Width × Height): 287mm×232mm×60mm.
- Weight: Gross weight is 2.9kg, and net weight is 2.05kg.
- Screen Type: TFT color, LED – backlit, touch screen.
- Real – Time Clock: Hardware clock with backup battery.
- Security: Password protection with 8 user levels.
- Serial Port 1 Type: RS232/RS422/RS485.
- USB Port Types: 2 USB 2.0 Host interfaces.
- Service Life: 40000 hours.
Product Performance
- High – Definition Display: The 10.4 – inch TFT screen, combined with high resolution and rich color display, can clearly and accurately present industrial data and complex images, facilitating operators to quickly and accurately obtain information.
- Convenient Interactive Operation: The sensitive multi – touch function enables smooth operation and rapid response, greatly improving the user’s operation experience and making industrial control operations more convenient and efficient.
- Advantages in Remote Monitoring: The built – in Web server supports remote access and control through a browser, breaking through geographical limitations. It allows engineers to monitor and maintain industrial equipment anytime and anywhere, improving equipment operation efficiency and maintenance timeliness.
- Multi – Function Integration: It supports various core functions of industrial automation, such as process monitoring, alarm management, data recording, and human – machine interaction, providing comprehensive support for industrial automation systems.
- Industrial – Grade Reliability: With a high protection level, the front is IP66, which can effectively resist dust and water splashing, and the housing is IP20, which can also provide basic protection. It can operate stably within the specified operating and storage temperature ranges and has strong anti – interference ability, making it suitable for harsh industrial environments.
- Flexible Expandability: Multiple communication interfaces and expansion slots facilitate the connection of various external devices and functional expansion, and the system can be flexibly configured according to different industrial application scenarios.
