ABB CMA130 3DDE300410 Analog input module
Specific Parameters
Electrical Parameters
Operating Voltage: 24VDC (±10%), supporting stable wide-range inputInput Channels: 8 independent analog input channels, mutually isolated between channelsInput Signal Types: Compatible with 4-20mA DC current signal, 0-10V DC voltage signal, PT100/PT1000 platinum resistance signalMeasurement Accuracy: ±0.1% of full scale, ensuring signal collection accuracyResolution: 16-bit, accurately capturing subtle signal changesIsolation Level: Electrical isolation between channels and between channels and power supply, isolation voltage 500V ACCommunication Protocols: Supports Profibus DP, EtherNet/IP, Modbus TCP mainstream industrial protocolsProtection Features: Built-in overvoltage protection, short circuit protection, reverse polarity protectionCertification Standards: Compliant with CE, UL, IEC 61158, IEC 61010-1 standards
Mechanical Parameters
Overall Dimensions: 100mm×80mm×35mm, compact structure suitable for dense installationWeight: Approximately 0.4kg, lightweight design facilitating deploymentMounting Method: 35mm DIN rail mounting, compatible with standard industrial control cabinetsHousing Material: Industrial-grade high-strength alloy, with both anti-electromagnetic interference and mechanical protection performanceConnection Method: Plug-in spring terminals, compatible with 0.5-1.5mm² shielded cablesProtection Rating: IP20, suitable for indoor control cabinet installation scenariosStatus Indication: Equipped with power (green), operation (yellow), channel fault (red) LED indicators
Environmental Parameters
Operating Temperature: -20℃ to 70℃, operation without derating over the entire temperature rangeStorage Temperature: -40℃ to 85℃, meeting extreme storage and transportation requirementsRelative Humidity: 5% to 95% (non-condensing), suitable for high-humidity industrial scenariosVibration Resistance: Complies with IEC 60068-2-6 standard, 3g acceleration at 3Hz-57Hz frequency range, 5g acceleration at 57Hz-500Hz frequency range (sine wave)Shock Resistance: Complies with IEC 60068-2-27 standard, 15g acceleration (half-sine wave, duration 11ms)EMC Compliance: Complies with EN 55014-1, EN 55014-2 standards, with standard anti-external electromagnetic interference capability
Product Performance
Excellent collection accuracy: ±0.1% full-scale accuracy combined with 16-bit resolution, accurately restoring the true value of process variablesReliable channel isolation: 500V electrical isolation design, avoiding inter-channel interference and voltage impact, ensuring signal purityWide signal compatibility: Supports multi-type input of current, voltage and thermal resistance, adapting to various industrial sensorsFlexible communication integration: Multi-protocol support enables seamless connection to mainstream control systems, realizing real-time data uploadConvenient installation and maintenance: Modular structure + plug-in terminals, reducing disassembly difficulty and operation and maintenance costsStrong environmental adaptability: Wide temperature operation and strong anti-interference design, tolerating complex working conditions such as dust and electromagnetic interferenceHigh operational reliability: Industrial-grade components and multiple protection mechanisms, Mean Time Between Failures (MTBF) ≥300,000 hoursOutstanding system compatibility: Perfectly adapts to ABB AC800M control system, and can be seamlessly integrated with third-party DCS and PLC
