ABB CI626V1 3BSE012868R1 communication interface module
The ABB CI626V1 3BSE012868R1 is a communication interface module used for data communication and interaction between devices in industrial automation systems. This module supports multiple communication protocols, can adapt to different types of devices, and enables the efficient integration and stable operation of the system. In the TMR (Triple Modular Redundancy) mode, it ensures the accuracy of data for each scan through the median selection algorithm. Its thermocouple input module is programmable and can support various thermocouple types such as J, K, and T. Each channel can perform auto - calibration to ensure the accuracy of measurement data. In addition, this module has a hot - spare function, allowing for the online replacement of faulty modules during equipment operation, reducing downtime due to equipment maintenance.
wechatPhone 15359273787
Phone: 15359273787
Email: sales@zzhuie.com
connect：Mya
ABB CI626V1 3BSE012868R1 communication interface module
Specific Parameters
- Operating Voltage: 24V DC
- Operating Temperature Range: From – 40°C to + 70°C
- Humidity Range: 5% to 95% (non – condensing)
- Dimensions: 2.5cm x 22.9cm x 30.5cm (1.0″ x 9.0″ x 12.0″)
- Weight: 1.44kg (3.2 lbs)
- Communication Protocol Support: Can support a variety of communication protocols (depending on the specific model)
- Signal Configuration: The factory setting for current output is 4 – 20 mA. The signal can be configured in “active” or “passive” mode (for devices operating in Zone 1 / Div. 1, the current output cannot be re – configured).
- PROFIBUS PA – related: The interface complies with the Profile 3.01 standard. The manufacturer – specific PROFIBUS PA ID number is 0x3430, and it can also operate with the standard IDs 0x9700 or 0x9740. The bus address needs to be checked or configured before start – up. If the customer does not provide it, the unit’s bus address is set to “126” by default. During start – up, it needs to be reset to a number within the valid range (0…125). The address can be set through DIP switches on the digital board, system tools, or PROFIBUS DP master class 2 (such as Asset Vision Basic). The factory setting for DIP switch 8 is OFF, meaning the address is set using the fieldbus.
Product Performance
- High – Reliability Communication: Adopting a redundant design and supporting multiple redundancy options, it ensures the stability of communication and the reliability of data transmission in complex industrial environments, effectively reducing the risk of communication interruption.
- High – Speed Data Transmission: It has fast data transmission capabilities and can efficiently handle a large amount of data interaction between devices, meeting the strict real – time requirements of industrial automation systems and improving the overall response speed of the system.
- Flexible Protocol Adaptation: Supporting multiple communication protocols, it can be seamlessly integrated with different brands and types of devices, greatly improving the versatility and compatibility of the module in diverse industrial automation scenarios.
- Precise Measurement and Diagnosis: The thermocouple input module supports multiple thermocouple types, and each channel is auto – calibrated with high measurement accuracy. At the same time, it performs complete and continuous diagnostics on each channel, which can detect and report faults in a timely manner, facilitating equipment maintenance and management.
- Convenient Maintenance Features: Supporting the hot – spare function and allowing for the online replacement of faulty modules, it reduces the difficulty and cost of equipment maintenance and improves the operational efficiency and availability of industrial automation systems.
