ABB CI540 3BSE001077R1 Analog I/O module

ABB CI540 3BSE001077R1 Analog I/O module

Specific Parameters​

• Number of Analog Inputs/Outputs: It has 4 – channel inputs (supporting voltage or current signals); there is also a configuration of 4 – channel inputs and 2 – channel outputs (supporting voltage or current signals).​
• Power Voltage: Multiple power voltage options are provided, including 24 VDC, 12 VDC, and 120/240 VAC.​
• Input Power Supply Rating: Corresponding to different power voltages, the ratings are 3 Watts (24 VDC), 2.25 Watts (12 VDC), 3 Watts (24 VDC), and 15 VA (120/240 VAC) respectively.​
• 24 VDC User Power for Sensors: It is 200 mA.​
• Analog Input Ranges: It supports a variety of input ranges such as 0 – 10V (10.23V), 0 – ±10V (±10.23V), 0 – 20 mA (20.47 mA), and 4 – 20 mA, with a resolution of 12 bits.​
• Analog Output Ranges: The output ranges include 0 to 10 VDC (10.24V), 0 to 20 mA (20.5 mA), and 4 to 20 mA (20.5 mA), and the resolution is also 12 bits.​
• Dimensions (Width x Height x Depth): 95mm x 90mm x 76mm.​

Product Performance​

• High Resolution: With a resolution of 12 bits, it can accurately measure and output analog signals, ensuring that industrial control systems obtain accurate data and providing strong support for precise control.​
• Flexible Range Setting: The measurement signal range of each channel can be set individually. Users can flexibly adjust the measurement range of each channel according to the actual application scenario to meet diverse industrial signal requirements.​
• Reliable Communication: When cooperating with the AC500 CPU and related interface modules, the communication is stable and reliable, and the data transmission is accurate, ensuring the stable operation of the industrial automation system.​
• Easy Expansion: It can be used as a local expansion module or achieve distributed expansion, which is convenient for industrial control systems to flexibly expand the system scale according to production needs.​
