ABB AI895 3BSC690089R1 Analog input module

ABB AI895 3BSC690089R1 Analog input module

Specific Parameters

• Electrical ParametersInput Channels: 8 independent analog input channels, supporting inter-channel isolationSignal Types: Compatible with thermocouples (Types J, K, T, E, R, S, B, N), RTDs (Pt100, Cu100), current (4-20mA, 0-20mA), voltage (0-10V, 0-5V, ±10V)Conversion Accuracy: 16-bit resolution; thermocouple measurement accuracy ±0.02% FS; RTD measurement accuracy ±0.01% FS; current/voltage measurement accuracy ±0.02% FSSampling Rate: Maximum single-channel sampling rate 100Hz, supporting channel group samplingIsolation Level: 2.5kVrms electrical isolation between input channels, 2.5kVrms isolation between input and systemPower Supply Voltage: 24V DC ±20%, supporting redundant power supplyPower Consumption: Typical 4W, maximum 6WDiagnostic Functions: Supports sensor open circuit, short circuit, reverse connection detection, and real-time output of fault alarm signals
• Environmental ParametersOperating Temperature: -40℃ to 70℃ (non-condensing environment)Storage Temperature: -40℃ to 85℃Relative Humidity: 5% to 95% (non-condensing)Protection Rating: IP20 (module itself)Anti-interference Performance: Complies with IEC 61326-1 industrial EMC standard; common-mode interference immunity ≥120dB; differential-mode interference immunity ≥60dBVibration Resistance: 10-500Hz frequency range, 1g acceleration (sine wave), 30 minutes per axis
• Mechanical ParametersOverall Dimensions: 100mm×160mm×30mm (standard I/O module size)Housing Material: Metal shielded case with anti-static coatingWeight: Approximately 300gMounting Method: 35mm standard DIN rail mounting or AC 800M system rack slot mountingStatus Indication: Front-panel LED indicators for power, operation, and channel fault status

Product Performance

Excellent signal acquisition accuracy: 16-bit AD conversion and high-precision calibration technology ensure that the measurement error of thermocouple, RTD and other signals is controlled within ±0.02% FS, meeting the high-precision monitoring needs of temperature, pressure and other parameters in industrial processes.

Outstanding anti-interference capability: 2.5kVrms high isolation design and electromagnetic shielding structure, with common-mode interference immunity up to 120dB, which can avoid signal distortion in industrial sites with dense high-power equipment and ensure stable data acquisition.

Efficient fault diagnosis: Real-time monitoring of abnormal states such as sensor open circuit and short circuit; triggers alarm and uploads diagnostic information within 100ms after fault occurrence; cooperates with LED indicators to quickly locate fault channels and reduce troubleshooting time.

Flexible system adaptation: Compatible with multiple sensor signal types, allowing access to different measurement equipment without replacing modules; supports redundant power supply and hot-swapping, enabling maintenance without system shutdown and improving equipment availability.

Convenient software integration: Seamlessly connects to ABB Control Builder M programming environment, provides pre-configured signal processing function library, enabling quick completion of channel parameter setting and data mapping, and reducing development cycle.
