ABB AI04 Analog input module
¥5,000.00 Original price was: ¥5,000.00.¥4,000.00Current price is: ¥4,000.00.
The ABB AI04 is an analog input module belonging to ABB's Symphony Plus series. It is specifically used to process signals from temperature sensors (thermocouples and millivolts) in industrial applications. It can process up to 16 thermocouple (TC) and millivolt (MV) signals. Each of the 16 channels can be configured independently. It is equipped with 4 analog - to - digital (A/D) converters, with each converter handling 4 input channels.
wechatPhone 15359273787
Phone: 15359273787
Email: sales@zzhuie.com
connect：Mya
ABB AI04 Analog input module
Specific Parameters
- Input Channels: 16.
- Supported Signal Types: Thermocouples (such as E, J, K, R, S, T, B, L, N, U, Chinese E, Chinese S, etc.), millivolt signals (0 – 100 mV, ±100 mV).
- Number of A/D Converters: 4.
- Channel Update Time: Update 16 channels within 300 milliseconds.
- Isolation Method: 2×8 – channel group isolation between channels.
- Measurement Accuracy: High – precision measurement within the full – scale range. The specific accuracy value depends on different signal types and ranges.
- Operating Voltage: Compatible with industrial standard voltages, usually within the common DC or AC operating voltage range (the specific value needs to be determined according to the actual product specifications).
- Module Dimensions: 263×58×28mm.
- Weight: 0.43kg.
- Compatible Mounting Bases: Can be mounted on a variety of vertical column mounting bases, such as VBS 01 – FPH, VBS 01 – FPN, VBS 01 – EPD, VBS 01 – CJC, VBS 01 – UAI, VBS 01 – SFP, and VBS 02 – EPD.
Product Performance
- High – Precision Measurement: With advanced signal – processing algorithms and high – resolution A/D converters, it achieves high – precision conversion and measurement of various analog signals, ensuring accurate and reliable collected data, meeting the industrial application scenarios with extremely high requirements for measurement accuracy.
- Independent Channel Configuration: Each channel can be configured independently. According to different measurement requirements, thermocouple types or millivolt signal ranges can be flexibly selected to meet the signal collection needs in diverse industrial environments.
- Fast Data Update: Complete the data update of 16 channels within 300 milliseconds, quickly respond to on – site signal changes, and provide the latest data for the control system in a timely manner, ensuring the real – time performance of the industrial automation system.
- Automatic Calibration and Compensation: Equipped with an automatic calibration mechanism, eliminating the need for frequent manual calibration. For thermocouple cold – junction compensation, it can be achieved through the embedded resistance temperature detector (RTD) in the module base or the application input configured by the user, ensuring long – term stable operation and measurement accuracy.
- High – Reliability Design: Adopts high – quality electronic components and optimized circuit design, can work stably in complex industrial environments, reduce failures, and improve the reliability and stability of the system.
- Convenient System Integration: It has good compatibility with other ABB automation products. It uses standard interfaces and communication protocols, which is convenient for integration into existing control systems, effectively reducing the difficulty of system upgrade and transformation.
