ABB 500MTM02 1MRB150020R0712 1HDF930512X010 Analog Output Module
ABB 500MTM02 1MRB150020R0712 1HDF930512X010 is an analog output module, mainly applied in industrial automation control systems. It can receive digital signals from Programmable Logic Controllers (PLCs), accurately convert them into corresponding analog signals, such as voltage or current signals, and then drive actuators, like control valves and servo motors. It realizes continuous regulation and control of parameters such as temperature, pressure, and flow in industrial production processes, and is an important bridge connecting digital control systems and analog execution equipment.
wechatPhone 15359273787
Phone: 15359273787
Email: sales@zzhuie.com
connect：Mya
ABB 500MTM02 1MRB150020R0712 1HDF930512X010 Analog Output Module
Specific Parameters
- Power Supply Parameters
- Supply Voltage: 24V DC
- Current Consumption: Maximum 0.15A
- Analog Output Channels
- Number of Channels: 4
- Output Signal Types: Voltage (0-10V, ±5V), current (4-20mA) configurable
- Output Accuracy: ±0.1% of full scale (at 25°C)
- Resolution: 16-bit
- Output Load: Minimum 10kΩ for voltage output; maximum 500Ω for current output
- Response Time: ≤100μs (from digital signal change to output stabilization)
- Isolation Characteristics
- Inter-channel Isolation: Available, isolation voltage 500Vrms
- Power Supply and Output Isolation: Available, isolation voltage 1000Vrms
- Physical Parameters
- Dimensions: 110mm in length, 80mm in width, 65mm in height
- Weight: Approximately 0.28kg
- Environmental Parameters
- Operating Temperature Range: -20°C to +60°C
- Storage Temperature Range: -40°C to +85°C
- Relative Humidity: 5% to 95% (non-condensing)
Product Performance
- High-Precision Signal Conversion: With 16-bit resolution and accuracy of ±0.1% of full scale, it ensures accurate conversion from digital signals to analog signals, and the output signals are stable. It can meet the high-precision requirements for parameter regulation in industrial production and ensure the stability of controlled parameters.
- Compatibility with Multiple Signal Types: It supports multiple analog output types of voltage and current, which can be flexibly configured according to the needs of actuators. No additional conversion equipment is needed, which enhances the versatility of the module and enables it to adapt to different types of actuators.
- Strong Isolation Performance: The isolation design between channels and between power supply and output effectively blocks the propagation of electromagnetic interference, reduces the impact of external interference on output signals, and ensures the accuracy and stability of output signals in complex industrial electromagnetic environments.
- Fast Response: With a response time of ≤100μs, it can quickly follow the changes of control signals from the PLC, adjust the output in time, and is suitable for control scenarios with high dynamic response requirements, such as fast-adjusting flow control links.
