ABB 500BIM01 1MRB150024R0002 Digital input module
The ABB 500BIM01 1MRB150024R0002 is a digital input module specifically designed for industrial automation control systems. In various industrial automation scenarios, this module is responsible for accurately collecting on - site digital signals, such as sensor status and switch position signals, and stably transmitting these signals to control devices such as Programmable Logic Controllers (PLCs), providing basic data support for automated control decisions. It is a key component to ensure the smooth operation of industrial automation processes.
wechatPhone 15359273787
Phone: 15359273787
Email: sales@zzhuie.com
connect：Mya
ABB 500BIM01 1MRB150024R0002 Digital input module
Specific Parameters
- Power Supply Parameters
- Supply Voltage: 24V DC
- Current Consumption: The maximum current consumption of the module itself is 0.05A
- Digital Input Channels
- Number of Channels: 8
- Input Type: Compatible with dry contacts or NPN/PNP transistor output types
- Input Signal Voltage: Signal 0 corresponds to -3V to +5V; Signal 1 corresponds to +15V to +30V
- Input Delay (0→1 or 1→0): The typical value is 5ms and can be configured in the range of 0.1 to 16ms
- Input Channel Current: When the input voltage is +24V, the typical value is 4mA
- Maximum Cable Length (Shielded): 1000m
- Maximum Cable Length (Unshielded): 600m
- Isolation Characteristics
- Channel – to – channel Isolation: Available, isolation voltage 500Vrms
- Power Supply and Signal Isolation: Available, isolation voltage 1000Vrms
- Dimensions: 100mm in length, 80mm in width, 60mm in height
- Weight: Approximately 0.25kg
- Operating Temperature Range: -20°C to +60°C
- Storage Temperature Range: -40°C to +85°C
Product Performance
- High – Precision Signal Collection: With its accurate recognition ability for input signals, it can collect on – site digital signals without error, ensuring reliable data for the control system. It effectively avoids control errors caused by signal misjudgment and guarantees the stability and reliability of industrial production.
- Compatibility with Multiple Input Types: It supports both dry contact inputs and seamless connection with NPN/PNP transistor output type devices, greatly improving the versatility of the module. It can be widely adapted to various industrial – site sensors, switches and other devices, facilitating its use in different industrial automation projects and reducing the difficulty of system integration.
- Strong Anti – interference Ability: Through the isolation design between channels and between the power supply and signals, it can effectively resist common electromagnetic interference in industrial environments, ensure the accuracy of signal transmission, reduce signal distortion and bit error rate. It can operate stably even in complex electromagnetic environments, improving the anti – interference performance of the entire automation system.
- Flexible Delay Configuration: The input delay can be flexibly adjusted in the range of 0.1 to 16ms. It can optimize the signal collection timing according to different application scenarios and device response characteristics, meet diverse industrial control requirements, and enhance the flexibility and accuracy of system control.
- Wide – Temperature – Range Adaptability: It can operate stably in the temperature range of -20°C to +60°C, adapting to a variety of harsh industrial environments. Whether it is a high – temperature metallurgical workshop or a low – temperature cold storage warehouse, its performance will not be affected by changes in ambient temperature, ensuring the continuous and stable operation of industrial automation systems throughout the year.
