ABB 3BHL000986P0006
ABB 3BHL000986P0006 is a core module in industrial automation control systems, integrating analog output and diode control functions. It adopts high-density circuit layout for compact design, and ensures stable operation in harsh industrial environments through military-grade manufacturing processes. The module can be directly connected to mainstream DCS systems such as ABB AC800M, establishing real-time communication with sensors and actuators through standardized interfaces, providing precise signal conversion and logic control support for automated processes, and serving as a key node connecting the control layer and equipment layer.
wechatPhone 15359273787
Phone: 15359273787
Email: sales@zzhuie.com
connect：Mya
ABB 3BHL000986P0006
Specific Parameters
- Rated operating voltage：DC 24V, allowable voltage fluctuation range 19.2V-28.8V, compatible with industrial universal DC power supply systems.
- Analog output channels：4 independent channels, supporting 4-20mA current signal and 0-10V voltage signal, output accuracy ±0.1%FS.
- Protection level：IP20, conforming to IEC 60529 standard, requiring a control cabinet for dust and moisture protection.
- Operating environment：Operating temperature -25℃-+70℃, relative humidity 5%-95% (non-condensing), vibration resistance level IEC 60068-2-6 (10-500Hz, 10g acceleration).
- Overall dimensions：160mm×100mm×40mm, adopting DIN rail mounting, with installation spacing ≥20mm.
- Weight：350g, including metal shielded housing, which can effectively reduce electromagnetic interference.
Product Performance
- High signal conversion accuracy：The linear error of 4 analog output channels is ≤0.05%FS, and the temperature drift coefficient is ≤5ppm/℃, maintaining output stability in the full temperature range of -25℃-+70℃, meeting the needs of precision control scenarios.
- Strong anti-interference ability：Built-in three-level EMC filter circuit, passing EN 61000-6-2 industrial environment immunity certification, resistant to 3kV surge impact and 10V/m electromagnetic radiation interference, ensuring normal operation around high-voltage motors and frequency converters.
- Fast response speed：The analog output step response time is ≤10ms (0-90%FS), supporting 1kHz signal refresh rate, which can track changes in control commands in real time, suitable for dynamic adjustment scenarios.
- Comprehensive diagnostic functions：Equipped with channel short-circuit protection, over-temperature protection and communication interruption self-recovery functions. Fault status can be synchronously fed back through LED indicators and bus signals, shortening fault troubleshooting time.
