ABB 3ASC25H214 DATX130 control module
Specific Parameters
- Electrical ParametersSupply Voltage: 24V DC, supporting 19.2-30V wide-range inputCPU Type: 32-bit high-performance processorMemory Capacity: 128KB program memory, 64KB data memoryCommunication Interfaces: 1×10/100M Ethernet (RJ45), 1×Profibus-DP master interfaceSupported Protocols: Modbus TCP, Ethernet/IP, Profibus-DPDigital Inputs: 16 channels, 24V DC signal inputDigital Outputs: 4 channels, relay output (2A per channel)Analog Inputs: 8 channels, 16-bit resolutionAnalog Outputs: 4 channels, 16-bit resolution
- Environmental ParametersOperating Temperature: -40°C to 70°CStorage Temperature: -40°C to 85°CProtection Class: IP20Anti-interference: Complies with IEC 61000-4 EMC standards
- Mechanical ParametersDimensions: 120mm×80mm×35mmWeight: Approximately 400gMounting Method: Standard DIN rail mounting
Product Performance
It features fast signal processing speed, with a boolean operation scan cycle as low as 0.08μs and a typical program scan cycle of 5ms/k instructions, enabling rapid response to real-time requirements such as high-speed counting and position control. Supports multi-task parallel processing, allowing assignment of safety logic and process control to independent tasks to improve system stability and maintainability. Communication response is efficient. Dual independent communication ports can simultaneously achieve high-speed data exchange with SCADA systems, HMI, and remote I/O, ensuring seamless integration of industrial networks. Equipped with comprehensive self-diagnostic functions, it can real-time monitor power supply, communication, and module status, triggering local alarms and remote signal uploads when faults occur. It has strong parameter compatibility, supports battery backup for programs and key data with no data loss after power failure, and is fully compatible with ABB Automation Builder platform, enabling custom control logic development through five standard programming languages.
