ABB 35DS91C GJR5137400R0003 Printed Circuit Board (PCB) module

ABB 35DS91C GJR5137400R0003 Printed Circuit Board (PCB) module

Specific Parameters

Module Type Printed Circuit Board Module

Order Number GJR5137400R0003

Product Model 35DS91C

Rated Operating Voltage 24VDC

Voltage Range 18-32VDC

Operating Temperature Range -40℃ to +70℃

Storage Temperature Range -40℃ to +85℃

Relative Humidity 5% to 95%, Non-Condensing

Protection Class IP20

Weight Approx.0.85kg

Mounting Type Standard 35mm DIN Rail Mounting, ABB System Rack Mounting

Electromagnetic Compatibility Compliant with EN 61000-6-2/6-4 Standards

Isolation Type Isolation between Power Supply and Signal, Isolation between Channels and System Bus

Power Consumption ＜16W (at 24VDC)

Diagnostic Functions Power Fault Diagnosis, Communication Fault Diagnosis, Bus Fault Diagnosis, Signal Abnormality Diagnosis, Channel Fault Diagnosis

Interface Type Standard Industrial Bus Interface, Digital Signal Input/Output Interface

Signal Processing Speed 120MHz

Response Time ＜0.8ms

Product Performance

Stable Signal Processing Performance: Built-in high-performance digital signal processing circuit, signal processing speed up to 120MHz, response time ＜0.8ms, can quickly process various digital signals in industrial field without delay or freeze, meeting the strict requirements of industrial real-time control scenarios.

Multiple Protection Performance: Adopts isolation design between power supply and signal, channels and system bus, with multiple protection functions such as overvoltage, overcurrent, short circuit and reverse connection, which can effectively prevent module damage and ensure stable system operation.

Redundant Fault-tolerant Performance: Adopts redundant design architecture, can automatically detect and isolate power supply, communication, bus and channel faults, and does not affect the overall operation of the system when a fault occurs, ensuring the continuity and stability of the industrial control process.

Comprehensive Diagnostic Performance: Built-in complete diagnostic functions including power fault, communication fault, bus fault, signal abnormality and channel fault, can monitor the module operation status in real time, quickly report faults to the system when faults occur, supports remote diagnosis and maintenance, and shortens fault troubleshooting time.

Anti-interference Performance: Complies with EN 61000-6-2/6-4 electromagnetic compatibility standards, possesses strong anti-interference ability, can effectively resist various interferences such as power grid harmonics, equipment start-stop impact and space electromagnetic radiation in industrial sites, no signal distortion and no false command issuance during long-term operation.

Wide Temperature Adaptation Performance: Operating temperature covers -40℃ to +70℃, can work stably in extremely cold or high-temperature environments, adapts to various harsh industrial sites, no constant temperature control required, trouble-free operation all-weather.

Hot Swap Performance: Supports online hot swapping, can replace the module without stopping the system, does not affect the overall system operation, reduces unplanned downtime and improves factory production efficiency.

System Compatibility Performance: Perfectly adapts to ABB Advant OCS/800XA series control systems, can be seamlessly connected with the same series of digital input/output modules, analog modules and communication modules, supports multiple communication protocols, completes system integration without additional debugging.
