ABB 086370-001 Digital Output Module
Specific Parameters
- Power Supply Parameters
- Supply Voltage: 24V DC (±10%)
- Power Consumption: ≤3W
- Output Parameters
- Number of Output Channels: 8 channels
- Output Type: Transistor output
- Maximum Output Current: 2A per channel
- Output Voltage Range: 24V DC
- Switching Delay Time: ≤5ms (turn-on), ≤3ms (turn-off)
- Isolation Parameters
- Channel-to-Channel Isolation: 500V AC (for 1 minute continuously)
- Output-to-Power Isolation: 1000V AC (for 1 minute continuously)
- Environmental Parameters
- Operating Temperature Range: -25°C to +70°C
- Storage Temperature Range: -40°C to +85°C
- Relative Humidity: 5% to 95% (non-condensing)
- Protection Class: IP20 (module body)
- Physical Parameters
- Mounting Type: Standard 35mm DIN rail mounting
- Dimensions: 105mm×82mm×32mm
- Weight: Approximately 0.22kg
Product Performance
- High Load Capacity: With a maximum output current of 2A per channel, it can directly drive small and medium-sized executive components without additional amplifier circuits, simplifying control loop design.
- Fast Switching Response: Turn-on delay ≤5ms and turn-off delay ≤3ms, enabling quick response to control instructions and meeting the control needs of high-frequency action equipment.
- Reliable Isolation Design: High voltage isolation between channels and between output and power supply effectively blocks the conduction of interference signals, ensuring stable operation of the module and control system.
- Stable Operation in Wide Temperature Range: Maintains stable performance within the temperature range of -25°C to +70°C, adapting to complex industrial environments with high or low temperatures.
- Strong System Adaptability: Deeply compatible with ABB’s mainstream PLC and DCS systems, supporting plug-and-play configuration and shortening system commissioning cycles.
