ABB 086348-001 Digital Input Module

ABB 086348-001 Digital Input Module

Specific Parameters

• Power Supply Parameters
  • Supply Voltage: 24V DC (±10%)
  • Power Consumption: ≤2.5W
• Input Parameters
  • Number of Input Channels: 8 channels
  • Input Signal Type: Dry contact/wet contact (configurable)
  • Input Voltage Range: 15-30V DC (wet contact)
  • Response Time: ≤10ms
• Isolation Parameters
  • Channel-to-Channel Isolation: 500V AC (for 1 minute continuously)
  • Signal-to-Power Isolation: 1000V AC (for 1 minute continuously)
• Environmental Parameters
  • Operating Temperature Range: -25°C to +70°C
  • Storage Temperature Range: -40°C to +85°C
  • Relative Humidity: 5% to 95% (non-condensing)
  • Protection Class: IP20 (module body)
• Physical Parameters
  • Mounting Type: Standard 35mm DIN rail mounting
  • Dimensions: 100mm×80mm×30mm
  • Weight: Approximately 0.2kg

Product Performance

• High Compatibility: Seamlessly interfaces with ABB AC500, AC800M and other series control systems, no additional adaptation modules required, simplifying system integration processes.
• Strong Anti-Interference Ability: Adopts optoelectronic isolation and electromagnetic shielding design, which can resist electromagnetic interference, surge and other interference signals in industrial sites, ensuring stable signal collection.
• Wide Voltage Adaptation: Supports 15-30V DC wide-range power supply and input, adaptable to different on-site power supply conditions, improving application flexibility.
• Fast Signal Response: With a signal response time of ≤10ms, it can capture changes in the status of on-site equipment in real time, meeting high real-time monitoring requirements.
• Stable Operation Ability: Continuously and stably operates in a wide temperature environment of -25°C to +70°C, resists humidity fluctuations, and adapts to complex industrial on-site environments.
