A-B 2098-DSD-150-DN Ultra 3000 Servo Drive – High Precision Motion Control for Industrial Automation
The Allen-Bradley 2098-DSD-150-DN Ultra 3000 Digital Servo Drive is an advanced solution designed to optimize machine system productivity. It’s built for automation systems and seamlessly integrates with Allen-Bradley Logix 5000 series controllers and SERCOS interfaces. This drive controls 3-phase motors and offers robust protection against bus overvoltages.
Input Voltage:100-240 VAC
Input Frequency:47-63 Hz
Continuous Output Current:15 A
Continuous Power Output:1.5 kW
Bus Overvoltage Protection:452 VDC
Shunt On:420 VDC
Weight:22.96 lbs
Dimensions:5.68 x 2.86 in (198.12 x 144.27 x 72.64 mm)
The Allen-Bradley 2098-DSD-150-DN Ultra 3000 Servo Drive is engineered for robust performance and reliability in demanding industrial environments. Designed with the latest technology, it offers seamless integration with the ControlLogix platform and SERCOS interface, enabling sophisticated motion control capabilities.
With a broad input voltage range of 100-240V AC, this servo drive ensures compatibility with a wide array of power sources, making it versatile for global applications. Its continuous power output of 5 kW supports high-torque operations, ideal for large-scale machinery.
This model is equipped with advanced safety features such as bus overvoltage protection up to 810V DC, ensuring safe and reliable operation under varying conditions. The internal shunt resistance of 40 Ohms provides additional safeguards against electrical surges.
Its compact dimensions of 5.68 x 2.86 in (144.27 x 72.64 mm) and lightweight design make it easy to integrate into existing systems without requiring significant space modifications. The auxiliary power supply feature adds convenience by allowing the drive to operate independently of the main power source.
For enhanced precision and efficiency, the 2098-DSD-150-DN incorporates an indexing feature that allows for pre-configured relative or absolute moves, perfect for applications requiring intricate motion control. Whether you’re involved in product assembly, cutting, or other automated processes, this servo drive delivers the accuracy and speed needed for high-level precision.
